Temperature Sensor

Thermistor for laser printer

Guangdong JPET Technology Co., LTD is a professional R & D and manufacturer of NTC temperature sensor, NTC thermistor and temperature switch.
JPH series NTC temperature sensors is used for temperature monitoring of office automation equipment (laser printer, duplicator roller shaft)
with characteristic of fast reaction,high precision, high reliability and high temperature resistance, including JPI/JPH/JPL/JPP/JPS/JPF series.

Features:

1.Small size glass encapsulated thermistor

2.Light contact type, long life
3.Quick reaction and wear resistance
4.Light contact can reduce roller damage


Applications:
1.Printed
2.Copier,photocopier
3.compound machine
4.Color multifunction printer


Product parameter characteristics:
1.Reaction time: ≦10S
2.Dissipation factor: about 0.3mW/℃
3.Operating temperature range：0℃-230℃
4.withstand voltage test:AC1000V
5.Insulation resistance: 100 m Ω DC500V

Dimensions:

Ordering instructions：

Please inform the following parameters when ordering NTC temperature sensor:
1.Resistance value requirements (can be selected according to the above table)
2.B value requirements (can be selected according to the above table)
3.Application: which type of printer, copier and so on
4.Accuracy requirement (1%-5% optional)
5.Exterior structure:OI,OS,OP,OH,OL series
6.Wire and length can be customized
7.If connectors are needed at the end of the wire(Molex, JST, CJT and others are optional).
We are professional manufacturer of NTC thermistors and temperature sensors. The products are including many parameters and specifications, please confirm before place an order.


Electrical Characteristics：
